Technical Specifications
| Capacity: | 2TB |
| Form Factor: | M.2 2280 |
| Write Host Performance Data Transfer(ATTO): | Up to 2900 MB/s |
| Read IOPS Random(4K) QD=32(Max): | 230,000 |
| System Reliability(MTBF): | 1,500,000 Hours |
| Active Read Power Consumption: | 3820mW |
| Idle Power Consumption: | <70mW |
| Non-Operating Temperature: | -40°C to 85°C |
| Shock: | 1500G, non-operational |
| Drive Dimensions(LxWxH): | 3.15in x 0.87in x 0.08in |
| Compliance: | CE, FCC, RoHS, WHQL, PCI Express Base 3.1, NVMe 1.3 |
| Host Interface: | PCIe Gen 3.0 x4 |
| Read Host Performance Data Transfer(ATTO): | Up to 3000 MB/s |
| Flash: | 3D NAND |
| Write IOPS Random(4K) QD=32(Max): | 390,000 |
| TBW Rating: | 1200TB |
| Active Write Power Consumption: | 3740mW |
| Operating Temperature: | 0°C to 70°C |
| Humidity: | 5% to 90%, non-condensing |
| Vibration: | 20Hz~80Hz/1.52mm frequency/displacement, 80Hz~2000Hz/20G frequency/acceleration |
| Warranty: | 5 Year Limited Warranty* |
