Description

TP-LINK TL-SF1008D. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100), Basic switching RJ-45 Ethernet ports quantity: 8. Full duplex. MAC address table: 1000 entries, Switching capacity: 1.6 Gbit/s. Networking standards: IEEE 802.3,IEEE 802.3ab,IEEE 802.3x. Power connector: DC-in jack 8 10/100Mbps auto-negotiation RJ45 ports, supports auto MDI/MDIX Green Ethernet technology saves the power up to 60% IEEE 802.3x flow control provides reliable data transfer Plastic case, desktop design Plug and play, no configuration required

Product Properties

• Manufacturer
• TP-LINK

• Model
• TL-SF1008D V10

• EAN
• 6935364083106

• Bullet points

• Point
• 8 10/100Mbps auto-negotiation RJ45 ports, supports auto MDI/MDIX
  Green Ethernet technology saves the power up to 60%
  IEEE 802.3x flow control provides reliable data transfer
  Plastic case, desktop design
  Plug and play, no configuration required

• Data transmission

• MAC address table
• 1000 entries

• Store-and-forward
• Y

• Switching capacity
• 1.6 Gbit/s

• Design

• Certification
• FCC, CE, RoHS

• Product colour
• White

• Rack mounting
• N

• Management features

• Switch type
• Unmanaged

• Network

• 10G support
• N

• Auto MDI/MDI-X
• Y

• Auto-negotiation
• Y

• Copper ethernet cabling technology
• 10BASE-T,100BASE-TX

• Flow control support
• Y

• Full duplex
• Y

• Networking standards
• IEEE 802.3,IEEE 802.3ab,IEEE 802.3x

• Operational conditions

• Operating relative humidity (H-H)
• 10 - 90%

• Operating temperature (T-T)
• 0 - 40 °C

• Storage relative humidity (H-H)
• 5 - 95%

• Storage temperature (T-T)
• -40 - 70 °C

• Packaging data

• AC adapter included
• Y

• Package type
• Box

• Performance

• Plug and Play
• Y

• Ports & interfaces

• Fast Ethernet (copper) ports quantity
• 8

• Power connector
• DC-in jack

• Switch Number of Ports
• 8

• Switch Port Speed
• Fast Ethernet (10/100)

• Power

• AC input frequency
• 50 Hz

• AC input voltage
• 220 V

• Output current
• 0.6 A

• Output voltage
• 9 V

• Power consumption (max)
• 2.05 W

• Power over Ethernet (PoE)

• Power over Ethernet (PoE)
• N

• Protocols

• Supported network protocols
• CSMA/CD, TCP/IP

• Weight & dimensions

• Depth
• 79 mm

• Height
• 22.5 mm

• Width
• 134.5 mm
